# 基本知识
# 常用设置
xAxis: {
type: 'category',
data: dataKeys,
name: "公司名",
interval:5, // 步长
min:10, // 起始
max:50 // 终止
axisLabel: {
interval: 0, //强制显示所有标签
rotate: 30 //X轴标签旋转（顺时针计算）
},
},
yAxis : [{
type : 'value',
scale : true,
min:0, // 起始
max:5, // 终止
interval:1, // 步长
splitNumber : 5, //y轴值间隔数量
axisLine: {
show: false,
lineStyle: {
type: 'solid',
color: '#5A5A5A',//左边线的颜色
width: '1'//坐标线的宽度
}
},
axisLabel: {
textStyle: {
color: '#5A5A5A',//坐标值得具体的颜色
}
},
axisTick:false,
splitLine: { //坐标轴在grid区域中的分隔线（网格中的横线）
show: true,
lineStyle: {
color: ['#5A5A5A'],
width: 1,
type: 'dashed',
}
},
splitArea: {//坐标轴在grid区域中的分隔区域（间隔显示网格区域）
interval: 1, //显示间隔的规律
show: true,
areaStyle: {//分隔区域的样式
color: ['rgba(255,255,255,0.03)', 'rgba(255,255,255,0)']
}
}
}],
# 常用方法
# echarts做飞线图
<!DOCTYPE html>
<html>
<head>
<meta charset="utf-8">
<title>飞线图</title>
<script src="https://cdn.bootcss.com/echarts/4.4.0-rc.1/echarts-en.js"></script>
<style>
html{
height: 100%;
}
body{
height: 100%;
margin: 0;
padding: 0;
background-color:#2F4056;
}
</style>
</head>
<body>
<div id="chart-box" style="width:100%; height:100%;"></div>
<script type="text/javascript">
const chart = echarts.init(document.getElementById('chart-box'));
const xhr = new XMLHttpRequest();
xhr.open('get','https://geo.datav.aliyun.com/areas/bound/530000_full.json',true)
xhr.send(null)
xhr.onreadystatechange = () => {
if ((xhr.status >= 200 && xhr.status < 300) || xhr.status == 304){
const data = JSON.parse(xhr.responseText);
console.log(Object.prototype.toString(data))
const coord = data.features.map(val => {
return {
name:val.properties.name,
value:val.properties.center
}
})
const lines_coord = [];
coord.forEach((v,index)=> {
index > 0 && lines_coord.push({
coords:[v.value,coord[0].value]
})
})
//地市取简称
data.features.forEach(v => {
v.properties.name = v.properties.name.indexOf('版纳')>-1 ?v.properties.name.substr(0,4) : v.properties.name.substr(0,2);
})
echarts.registerMap('yns', data);
const option ={
title: {
text: '云南省',
},
geo: {
map: 'yns',
zlevel: 10,
show:true,
layoutCenter: ['50%', '50%'],
roam: false,
layoutSize: "90%",
zoom: 1,
label: {
normal: {
show: true,
textStyle:{
fontSize:12,
color: '#43D0D6'
}
}
},
itemStyle: {
normal: {
color: '#062031',
borderWidth: 1.1,
borderColor: '#43D0D6'
}
},
emphasis: {
areaColor: '#FFB800',
label:{
show:false
}
}
},
series: [
{
type:'effectScatter',
coordinateSystem: 'geo',
zlevel: 15,
symbolSize:8,
rippleEffect: {
period: 4, brushType: 'stroke', scale: 4
},
itemStyle:{
color:'#FFB800',
opacity:1
},
data:coord.slice(1)
},
{
type:'effectScatter',
coordinateSystem: 'geo',
zlevel: 15,
symbolSize:12,
rippleEffect: {
period: 6, brushType: 'stroke', scale: 8
},
itemStyle:{
color:'#FF5722',
opacity:1
},
data:coord.slice(0,1)
},
{
type:'lines',
coordinateSystem:'geo',
zlevel: 15,
effect: {
show: true, period: 5, trailLength: 0, symbol: 'arrow', color:'#01AAED',symbolSize: 8,
},
lineStyle: {
normal: {width: 1.2, opacity: 0.6, curveness: 0.2, color: '#FFB800'}
},
data:lines_coord
}
]
}
chart.setOption(option);
chart.on('click', function (params) {
console.log(params);
});
} else {
alert(xhr.status);
}
}
</script>
</body>
# 使用背景图的柱状图
var min = 0.9;
var myChart = echarts.init(document.getElementById('container'));
option = {
xAxis: {
type: 'category',
data: ['A', 'B', 'C', 'D', 'E']
},
yAxis: {
type: 'value',
min: min
},
series: [{
type: 'custom',
renderItem: function (params, api) {
var dataIndex = api.dataIndex;
var xValue = api.value(0);
var yValue = api.value(1);
var xCoord = api.coord([xValue, yValue])[0];
var yCoord = api.coord([xValue, yValue])[1];
var startYCoord = api.coord([xValue, min])[1];
var barWidth = api.size([1, 0])[0] * 0.3;
return {
type: 'group',
children: [
{
type: 'image',
style: {
x: xCoord - barWidth / 2,
y: yCoord,
width: barWidth,
height: startYCoord - yCoord,
image:tcon
}
}
]
};
},
data: [['A', 1.1], ['B', 1.12], ['C', 1], ['D', 0.99], ['E', 0.98]]
}]
};
myChart.setOption(option);
